There are many DDoS mitigation methods, and each has its advocates. The three most common DDoS mitigation methods are Clean Pipe, CDN Attack Dilution, and Anti-DDoS Proxy.

The truth is, there’s no such thing as “the best mitigation method”, there’s only the most suitable method depending on different use cases. We’ll dive into each method mentioned above and help you understand and choose the best method for you.

Clean Pipe

Clean Pipe is one of the most common DDoS mitigation implementation methods of all three. To implement it, all incoming traffic must pass through a cleaning center also known as a “scrubbing center”, where malicious traffic is identified and separated permitting only legitimate traffic to get to the server.

With the rise of DDoS attacks, many Internet Service Providers (ISPs) and Managed Security Service Providers (MSSPs) have begun to offer anti-DDoS services often referred to as “Clean Pipe”, where in the past, organizations were handling DDoS attacks with black-holing.

Clean Pipe is famous for its complexity of deployment. You need to have:

  1. BGP router
  2. A network device with the capability to terminate a GRE tunnel
  3. Internet routable prefixes and ASN

Constraints of Clean Pipe

  1. Detection and re-route lead time – Every time an attack on a customer is detected, re-routing techniques are needed to send the traffic to a center. This involves a detection diversion process that requires mitigation detection and takes at least several minutes from re-route to eventually mitigation kick-in which the enterprise online services are not protected and are exposed to the attackers.

  2. Incomplete mitigation and high false-positive – The Clean Pipe method does not provide complete protection against DDoS attacks. Firstly, they lack the capacity to handle just average size attacks, especially when it comes to packet-based / application flood attacks. Secondly, your IP prefix is not hidden. In contrast, an attacker can easily identify your infrastructure provider and exploit the loophole and weakness.

    Besides, Clean Pipe re-route involves the entire prefix, typically it is at least /24. Under /24, computers with /24 might send traffic out as a client (for instance, query a DNS), and send traffic out as a server (for instance, serving web content). The mixing profile of the client and server-side traffic makes the mitigation profile very complex and introduces lots of false positives and therefore, you will find Clean Pipe often requires a lot of human intervention.

  3. Mitigation Granular and Effectiveness – A cleaning center is designed to only drop malicious traffic but they cannot prevent an original attack. Security isn’t always a core capability of an ISP and they often don’t have the security expertise of a dedicated DDoS mitigation provider. As they are more focused on the volume of the attacks instead of focusing on signature and type of the attack. Hence leaving them vulnerable to the application layer/slow DDoS attacks.

High versatility is the key benefit of Clean Pipe method, as it supports almost all application in IP stack. But versatility has a tradeoff, it lacks advanced protection for a specific application, incurs high mitigation false-positive and high cost, which is critical for customers nowadays.

However, Clean Pipe is criticized because it’s coarse-grained. For instance, when trying to enable TCP RESET to counter TCP SYN Flood, some applications re-connect automatically without issue, but browsers may not be so lucky on the other hand.

CDN Dilution

Content delivery network (CDN) is a system of distributed servers (network) that deliver pages and other web content to a user. CDN is also known for its huge capacity in networking and the design of distribution of traffic. CDN Dilution is basically using the huge bandwidth CDN technology is offering to mitigate to absorb L3/L4 DDoS attacks. We’ve covered more about how CDN (or specifically Multi CDN) can help you fight DDoS attacks effectively, read more here.

mlytics ddos protection
CDN can dilute DDoS attacks with its massive bandwidth like a whale

CDN edge servers are working as reverse proxy for web application. All requests will be handled by the edge server, and malicious requests will be filtered out before sending back to the origin.  CDN Dilution offers the most comprehensive DDoS protection because:

  1. CDN edge servers are application context-aware
  2. A well-defined protocol (HTTP)
  3. It is always-on and no lead time

However, CDN Dilution only applies to web applications. If you are using a proprietary TCP/UDP application, then CDN Dilution won’t help.

Anti-DDoS Proxy

If you run TCP or UDP services on your origins such as web-servers, gaming services, remote server access (SSH), or email (SMTP), they are exposed through open ports. This means malicious attackers can send volumetric DDoS traffic or attempt to snoop sensitive, unencrypted data.

Some providers especially MSSP and CDN providers saw this demand and build reversed TCP/UDP proxy in their existing DDoS infrastructure to offer an extract layer of protection to TCP/UDP application.

The Anti-DDoS Proxy works similarly to CDN. Packets are sent to reverse proxy and filter out malicious packets with a defined mitigation profile. Anti-DDoS Proxy offers an intermediate comprehensive level of DDoS protection with the following advantages:

  1. Always-On and no lead time
  2. A positive security model (allow defined port to access rather than open all)
  3. Able to fight against slow DDoS attack

A significant trade-off is that the source IP has changed for the backend. This may be a lethal issue to some of the applications given there is no way to get the real visitor’s IP.

Clean Pipe vs CDN Dilution vs Anti-DDoS Proxy

The differences between Clean Pipe, CDN Dilution, and Anti-DDoS Proxy (TCP/UDP Proxy) are huge. Though, they are not mutually exclusive and can supplement each other as a holistic solution. To simplify and conclude everything, here’s a comparison table to clear the air:


CDN Dilution Anti-DDoS Proxy Clean Pipe
Deployment mode Reversed proxy Proxy Tunnel
Support application Web application, static content, dynamic content, web socket Any TCP or UDP application Any application
Configuration Per-domain basis Per application basis Per prefix basis
Deployment prerequisites Internet Internet Support BGP Support TunnelRoutable /24 Prefix
Deployment lead time Minutes Minutes Days
Origin load balancing Support Support Not Support
L3/L4 DDoS protection Yes, always ON Yes, always ON Yes but usually not always ON
False-positive Low Medium to Low High
L7 mitigation capability High Medium/Low Medium/Low
Others benefits Content cache, web application firewall, application layer logging Supports multiple ports on the same hostname or application, aka backend load balancing Usually involves zero application changes
Constraints Only applies to web application Client IP will be replaced by proxy source-NAT IP. The origin server will not see the real IP anymore. High false-positive and false-negative due to traffic profile mixed with client and server.

Where to start

There are many ways to implement DDoS mitigation strategies, but oftentimes it’s difficult to create everything from scratch. As mentioned in this article:

It may seem unfortunate to have to pay to be properly protected against DDoS attacks, but remaining unprotected puts companies at great risk in terms of potential damages, time lost, and diminished customer trust.

It’s hard to avoid spending money on DDoS mitigation services nowadays even for small/mid businesses. But what we can do is find a way to put these investments to work when no attack is happening. Most DDoS mitigation services charge businesses money regardless of an attack is happening or not, except the DDoS mitigation service that uses CDN Dilution method.

Since the CDN Dilution method is built on CDN technology, businesses can still utilize the CDN to deliver their web assets during peaceful period; when an attack occurs, the CDN can be used to dilute DDoS attacks. The mlytics Enhanced Security feature is build based on this philosophy, which uses Multi CDN to absorb massive DDoS attacks and boost website performance.

mlytics DDoS protection (powered by Multi CDN) for the network layer (L3/L4) is available under Pro plan; protection for the application layer (L7) is available under Business plan. Learn more on the pricing page.
